Detailed introduction

---

Application advantages：
Face detection temperature measurement
It can effectively eliminate non temperature measurement target interference.
Intelligent compensation
It can automatically compensate the temperature measurement results according to the environmental parameters to ensure the temperature measurement accuracy and screening rate.
Integration of personnel and certificates
It can quickly lock the identity of the target with abnormal body temperature
Improve the work efficiency of pre-warning, handling and post tracing.

Product parameters
·High resolution 384 × 288 high sensitivity uncooled vanadium oxide detector
·Low power consumption < 2W
·NETD＜35mk@F1.0,25°C
·Temperature measurement range: 20 ℃ ~ 45 ℃
·Temperature measurement accuracy ≤± 0.3 ℃
·Temperature measurement response < 300 ms

Function features
·Real time image output, support auto focus and gray alarm function
·Support IP access and rich image adjustment functions
·Optional with 50mm, 75mm, 20-100mm, etc
·Device supports external large capacity storage function
·Support the use of PELCO-D and other protocols to control the PTZ through 485 interface
·Support the dual backup function of the system to ensure that the data is not lost in case of power failure
·Support SDK access and control, support ONVIF protocol
·Full screen temperature detection
·Pixel flicker in over temperature area
·Audible and visual alarm function
·Powerful software interface
·Automatic time and event storage function
